Setting Up Cloudflare Tunnel

Hey guys!

It’s Juke here.
This time, I tried publishing a gonic server using Cloudflare Tunnel.
I set it up on a Raspberry Pi running Ubuntu Server version 22.04.3.
Check out my video for an overview of the setup.

【Build】 Make your server public with Cloudflare Tunnel! 【JUKE UNOTSUKI】

Alright, let’s get started.

Prerequisites

• You have a Cloudflare account
• You own at least one custom domain

Installing cloudflared (Official APT)

We’ll install cloudflared from the official Cloudflare repository.

Registering the “Signature Key” for Securely Using Cloudflare’s APT Repository on Ubuntu

curl -fsSL https://pkg.cloudflare.com/cloudflare-main.gpg \
 | sudo tee /usr/share/keyrings/cloudflare-main.gpg >/dev/null

Register the official package distribution server for cloudflared on Ubuntu

 echo "deb [signed-by=/usr/share/keyrings/cloudflare-main.gpg] \
https://pkg.cloudflare.com/cloudflared$(lsb_release -cs) main" \
| sudo tee /etc/apt/sources.list.d/cloudflared.list

apt update

sudo apt update

Install cloudflared

sudo apt install -y cloudflared

Verify successful installation

cloudflared version

Log in to Cloudflare Tunnel

Once cloudflared is installed, log in to Cloudflare.

cloudflared tunnel login

• Copy the displayed URL
• Launch your browser
• Log in to Cloudflare
• Paste the copied URL into your browser
• Select the domain you want to use

If successful, the following directory and file will be created:

~/.cloudflared/cert.pem

• cert.pem is only used when creating a Tunnel

Creating a Tunnel

Once logged into Cloudflare, create your tunnel.

cloudflared tunnel create my-tunnel

Replace my-tunnel with any name you like.

Upon success, a .json file will be created in .cloudflared.

Tunnel credentials written to ~/.cloudflared/xxxxxxxx-xxxx.json

• xxxxxxxx-xxxx.json contains the core Tunnel credentials
• The UUID is the Tunnel ID

Make a note of the ID and the .json filename somewhere.

Assigning the Created Tunnel to Your Domain

For example, to assign app.example.com to my-tunnel, use the following command:

cloudflared tunnel route dns my-tunnel app.example.com

Correct Configuration for systemd Operation

Key Design Principles

Create Configuration Directory

sudo mkdir -p /etc/cloudflared
sudo chown root:root /etc/cloudflared
sudo chmod 755 /etc/cloudflared

Move credentials JSON

sudo mv ~/.cloudflared/xxxxxxxx-xxxx.json /etc/cloudflared/
sudo chown root:root /etc/cloudflared/xxxxxxxx-xxxx.json
sudo chmod 600 /etc/cloudflared/xxxxxxxx-xxxx.json

※ You don’t need to move cert.pem

Create config.yml

sudo vi /etc/cloudflared/config.yml

Minimal Configuration Example (HTTP 1 Service)

tunnel: xxxxxxxx-xxxx-xxxx-xxxx-xxxxxxxxxxxx
credentials-file: /etc/cloudflared/xxxxxxxx-xxxx.json

ingress:
  - hostname: app.example.com
    service: http://127.0.0.1:8080
  - service: http_status:404

Validate Configuration File

sudo cloudflared tunnel ingress validate

If no errors appear, it’s OK

Register systemd Service

sudo cloudflared service install

Start & Enable Auto-Start

sudo systemctl enable cloudflared
sudo systemctl start cloudflared
sudo systemctl status cloudflared

Verify Operation

Access the following URL in your browser. If the server appears, it’s successful.

https://app.example.com

Example of Publishing Multiple Services

ingress:
  - hostname: 01.example.com
    service: http://127.0.0.1:4616
  - hostname: 02.example.com
    service: http://127.0.0.1:4620
  - hostname: 03.example.com
    service: http://127.0.0.1:5000
  - service: http_status:404
